| STOCK NUMBER | SIZE | FEET/DRUM | WEIGHT/FOOT | WORKING LOAD LIMIT |
|---|---|---|---|---|
| ZPPC187 | 3/16 | 750, 1,500 | .41 lbs. | 750 lbs. |
| ZPPC250 | 1/4 | 400, 800 | .68 lbs. | 1,250 lbs. |
| ZPPC312 | 5/16 | 275, 550 | 1.02 lbs. | 1,900 lbs. |
| ZPPC375 | 3/8 | 200, 400 | 1.47 lbs. | 2,650 lbs. |
| ZPPC500 | 1/2 | 100, 200 | 2.52 lbs. | 4,500 lbs. |
| ZPPC625 | 5/8 | 75, 150 | 4.06 lbs. | 6,900 lbs. |
| ZPPC750 | 3/4 | 50, 100 | 5.81 lbs. | 10,600 lbs. |
Note: Grade 30, Grade 43, and Grade 70 chain are not suitable for overhead lifting.
| STOCK NUMBER | SIZE | FEET/DRUM | WEIGHT/FOOT | WORKING LOAD LIMIT |
|---|---|---|---|---|
| ZPPC187X250 | 3/16 | 250 | .41 lbs. | 750 lbs. |
| ZPPC250X141 | 1/4 | 133, 141 | .68 lbs. | 1,250 lbs. |
| ZPPC31292 | 5/16 | 92 | 1.02 lbs. | 1,900 lbs. |
| ZPPC37566 | 3/8 | 66 | 1.47 lbs. | 2,650 lbs. |
| ZPPC50035 | 1/2 | 35 | 2.52 lbs. | 4,500 lbs. |
Note: Grade 30, Grade 43, and Grade 70 chain are not suitable for overhead lifting.
WARNING: Prop 65: Products supplied by CERTEX USA may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
