| Specifications | |||
| Size of Chain | Grade 80 Working Load Limits* Lbs. at 90° | Grade 100 Working Load Limits* Lbs. at 90° | |
| In. | mm | ||
| 9/32 | 7 | 3,500 | 4,300 |
| 3/8 | 10 | 7,100 | 8,800 |
| 1/2 | 13 | 12,000 | 15,000 |
| 5/8 | 16 | 18,100 | 22,600 |
| 3/4 | 20 | 28,300 | 35,300 |
| 7/8 | 22 | 34,200 | 42,700 |
| 1 | 26 | 47,700 | — |
| 1-1/4 | 32 | 72,300 | |
WARNING: Prop 65: Products supplied by CERTEX USA may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
Electrolines’s closed-body swageless clevis turnbuckle can be quickly installed and tensioned in the field without special tools or processes. For ropes from 1/16 to 3/4 inches in diameter. Fitting strength exceeds the rated breaking strength of most ropes. Available...
Electroline’s industrial series clevis (fork/jaw) socket fitting includes a pin and cotter pin. It features a swageless rope termination that can be quickly installed in the field without special tools or processes. Available for ropes from 7/16 to 1 inches in size....
Electroline’s machined clevis fitting (fork/jaw) includes a pin and cotter pin and features a swageless rope termination that allows it to be quickly installed in the field without special tools or processes. Available for ropes from 1/16 to 1-1/2 inches in size....
Electroline’s forged wire rope clevis (fork/jaw) fitting includes a threaded pin and nut. It features a swageless rope termination that can be quickly installed in the field without special tools or processes. Available for ropes from 1/4 to 1-1/4 inches in size....
