REGULAR – This is the type that is sewn on to give fixed protection at expected wear points. They can be sewn anywhere on the sling, at any length on one side or on both sides.
| CERTEX Cat. Ref. No. | Size | A | B | C | D | E | F | G | Approx. Weight (lbs.) | Rated Capacity (lbs.) | Minimum Break |
|---|---|---|---|---|---|---|---|---|---|---|---|
| CX07-0091 | T2 | 4 | 3 5/8 | 2 1/4 | 1 3/4 | 15/16 | 2 3/8 | 9/16 | .31 | 3,360 | 16,800 |
| CX07-0092 | T3 | 5 1/4 | 5 | 3 1/4 | 2 | 1 3/16 | 3 5/16 | 5/8 | .75 | 5,000 | 25,000 |
| CX07-0093 | T4 | 6 1/4 | 6 5/8 | 4 3/8 | 2 3/8 | 1 7/16 | 4 | 11/16 | 1.1 | 6,700 | 33,500 |
| CX07-0094 | T6 | 8 5/16 | 8 7/8 | 6 3/8 | 3 1/8 | 1 3/4 | 5 1/2 | 15/16 | 2.7 | 9,700 | 48,500 |
WARNING: Prop 65: Products supplied by CERTEX USA may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
