APPLICATIONS
FEATURES
| ROPE SIZE DIAMETER | STOCK NUMBER | DESCRIPTION | REEL LENGTH | COLOR | WORKING LOAD LIMIT (lbs.) | MINIMUM BREAKING STRENGTH (lbs.) |
|---|---|---|---|---|---|---|
| 3/16” | NYLON187X600 | Nylon Twisted Rope | 600′ | White | 200 | 1,000 |
| 1/4” | NYLON250X600 | Nylon Twisted Rope | 600′ | White | 330 | 1,650 |
| 5/16” | NYLON312X600 | Nylon Twisted Rope | 600′ | White | 510 | 2,550 |
| 3/8” | NYLON375X600 | Nylon Twisted Rope | 600′ | White | 740 | 3,700 |
| 1/2” | NYLON500X600 | Nylon Twisted Rope | 600′ | White | 1,280 | 6,400 |
| 5/8” | NYLON625X600 | Nylon Twisted Rope | 600′ | White | 2,080 | 10,400 |
| 3/4” | NYLON750X600 | Nylon Twisted Rope | 600′ | White | 2,840 | 14,200 |
| 7/8” | NYLON875X600 | Nylon Twisted Rope | 600′ | White | 4,000 | 20,000 |
| 1” | NYLON100X600 | Nylon Twisted Rope | 600′ | White | 5,000 | 25,000 |
WARNING: Prop 65: Products supplied by CERTEX USA may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
Capacity Range: 1t ~ 10t Heavy Duty Quick Install Push Type Trolley Simple Installation, No Special Tools Required Fits both ‘S’ beams and ‘W’ beams Low Profile Design Corrosion Resistant Stainless Steel Plungers Corrosion Resistant Double Sealed Bearings Meets...
Adjustable to fit various beam widths A solid carbon steel design The wheels of the trolley fit both I-Beams and H-Beams Trolley wheels are parkerized for corrosion resistance High quality closed bearings provide smooth traversing With Anti-Drop plates Suitable for...
Adjustable to fit various beam widths A solid carbon steel design The wheels of the trolley fit both I-Beams and H-Beams Trolley wheels are parkerized for corrosion resistance High quality closed bearings provide smooth traversing With Anti-Drop plates Suitable for...
Solid carbon steel design Adjustable to fit various beam widths with traditional spacers Wheels of the units fit both I-beams and H-beams Trolley wheels are coated for corrosion resistance With anti-drop plates 100% stainless steel spark resistant & corrosion...
