| STOCK NUMBERS | SIZE | WORKING LOAD LIMIT | APPROXIMATE WEIGHT/PIECE | DIMENSIONS | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A | B | C | D | E | F | G | H | I | J | K | L | ||||
| TBEH250X4 | 1/4″ X 4″ | 400 lbs. | .31 lbs. | .25″ | .44″ | 1.67″ | 1.27″ | 11.66″ | 7.66″ | 12.29″ | 8.29″ | .81″ | .34″ | 1.76″ | 4.07″ |
| TBEH312X450 | 5/16″ X 4 1/2″ | 700 lbs. | .50 lbs. | .31″ | .50″ | 2.00″ | 1.50″ | 13.50″ | 9.00″ | 14.28″ | 9.78″ | .95″ | .44″ | 2.20″ | 4.58″ |
| TBEH375X6 | 3/8″ X 6″ | 1,000 lbs. | .79 lbs. | .38″ | .56″ | 2.28″ | 1.76″ | 17.09″ | 11.09″ | 18.04″ | 12.04″ | 1.13″ | .53″ | 2.48″ | 6.10″ |
| TBEH500X6 | 1/2″ X 6″ | 1,500 lbs. | 1.80 lbs. | .50″ | .65″ | 3.53″ | 2.28″ | 19.57″ | 13.57″ | 20.79″ | 14.79″ | 1.41″ | .71″ | 3.56″ | 6.03″ |
| TBEH500X9 | 1/2″ X 9″ | 1,500 lbs. | 2.35 lbs. | .50″ | .65″ | 3.53″ | 2.28″ | 25.69″ | 16.64″ | 26.94″ | 17.94″ | 1.41″ | .71″ | 3.56″ | 9.18″ |
| TBEH500X12 | 1/2″ X 12″ | 1,500 lbs. | 2.70 lbs. | .50″ | .65″ | 3.51″ | 2.28″ | 31.86″ | 19.86″ | 33.08″ | 21.08″ | 1.41″ | .71″ | 3.54″ | 12.36″ |
| TBEH625X6 | 5/8″ X 6″ | 2,250 lbs. | 2.98 lbs. | .63″ | .90″ | 4.24″ | 2.81″ | 21.11″ | 15.11″ | 22.61″ | 16.61″ | 1.90″ | .88″ | 4.35″ | 6.03″ |
| TBEH625X9 | 5/8″ X 9″ | 2,250 lbs. | 3.80 lbs. | .63″ | .90″ | 4.24″ | 2.81″ | 27.31″ | 18.21″ | 28.81″ | 19.70″ | 1.90″ | 88″ | 4.35″ | 9.18″ |
| TBEH625X12 | 5/8″ X 12″ | 2,250 lbs. | 4.35 lbs. | .63″ | .90″ | 4.23″ | 2.81″ | 33.45″ | 21.45″ | 34.95″ | 22.95″ | 1.80″ | .88″ | 4.34″ | 12.39″ |
| TBEH750X6 | 3/4″ X 6″ | 3,000 lbs. | 4.21 lbs. | .75″ | .98″ | .5.07″ | 3.33″ | 22.61″ | 16.61″ | 24.45″ | 18.45″ | 2.09″ | 1.00″ | 5.12″ | 6.13″ |
| TBEH750X9 | 3/4″ X 9″ | 3,000 lbs. | 5.58 lbs. | .75″ | .98″ | .5.07″ | 3.33″ | 28.81″ | 19.71″ | 30.65″ | 21.63″ | 2.09″ | 1.00″ | 5.12″ | 9.33″ |
| TBEH750X12 | 3/4″ X 12″ | 3,000 lbs. | 6.52 lbs. | .75″ | .98″ | 5.04″ | 3.33″ | 35.01″ | 23.01″ | 36.85″ | 24.85″ | 2.09″ | 1.00″ | 5.09″ | 12.59″ |
| TBEH750X18 | 3/4″ X 18″ | 3,000 lbs. | 8.24 lbs. | .75″ | .98″ | 5.07″ | 3.33″ | 47.01″ | 29.01″ | 48.85″ | 30.85″ | 2.09″ | 1.00″ | 5.12″ | 18.53″ |
| TBEH875X12 | 7/8″ X 12″ | 4,000 lbs. | 9.34 lbs. | .88″ | 1.13″ | 5.82″ | 3.78″ | 36.11″ | 24.11″ | 38.23″ | 26.23″ | 2.38″ | 1.25″ | 5.79″ | 12.16″ |
| TBEH100X12 | 1″ X 12″ | 5,000 lbs. | 13.9 lbs. | 1.00″ | 1.25″ | 6.56″ | 4.25″ | 37.65″ | 25.56″ | 40.06″ | 28.06″ | 3.00″ | 1.43″ | 6.50″ | 12.18″ |
| TBEH100X18 | 1″ X 18″ | 5,000 lbs. | 15.85 lbs. | 1.00″ | 1.25″ | 6.56″ | 4.25″ | 49.75″ | 31.65″ | 52.11″ | 34.11″ | 3.00″ | 1.43″ | 6.50″ | 18.28″ |
| STOCK NUMBERS | DIMENSIONS | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A | B | C | D | E | F | G | H | I | J | K | L | |
| TBEH250X4 | .25″ | .44″ | 1.67″ | 1.27″ | 11.66″ | 7.66″ | 12.29″ | 8.29″ | .81″ | .34″ | 1.76″ | 4.07″ |
| TBEH312X450 | .31″ | .50″ | 2.00″ | 1.50″ | 13.50″ | 9.00″ | 14.28″ | 9.78″ | .95″ | .44″ | 2.20″ | 4.58″ |
| TBEH375X6 | .38″ | .56″ | 2.28″ | 1.76″ | 17.09″ | 11.09″ | 18.04″ | 12.04″ | 1.13″ | .53″ | 2.48″ | 6.10″ |
| TBEH500X6 | .50″ | .65″ | 3.53″ | 2.28″ | 19.57″ | 13.57″ | 20.79″ | 14.79″ | 1.41″ | .71″ | 3.56″ | 6.03″ |
| TBEH500X9 | .50″ | .65″ | 3.53″ | 2.28″ | 25.69″ | 16.64″ | 26.94″ | 17.94″ | 1.41″ | .71″ | 3.56″ | 9.18″ |
| TBEH500X12 | .50″ | .65″ | 3.51″ | 2.28″ | 31.86″ | 19.86″ | 33.08″ | 21.08″ | 1.41″ | .71″ | 3.54″ | 12.36″ |
| TBEH625X6 | .63″ | .90″ | 4.24″ | 2.81″ | 21.11″ | 15.11″ | 22.61″ | 16.61″ | 1.90″ | .88″ | 4.35″ | 6.03″ |
| TBEH625X9 | .63″ | .90″ | 4.24″ | 2.81″ | 27.31″ | 18.21″ | 28.81″ | 19.70″ | 1.90″ | 88″ | 4.35″ | 9.18″ |
| TBEH625X12 | .63″ | .90″ | 4.23″ | 2.81″ | 33.45″ | 21.45″ | 34.95″ | 22.95″ | 1.80″ | .88″ | 4.34″ | 12.39″ |
| TBEH750X6 | .75″ | .98″ | .5.07″ | 3.33″ | 22.61″ | 16.61″ | 24.45″ | 18.45″ | 2.09″ | 1.00″ | 5.12″ | 6.13″ |
| TBEH750X9 | .75″ | .98″ | .5.07″ | 3.33″ | 28.81″ | 19.71″ | 30.65″ | 21.63″ | 2.09″ | 1.00″ | 5.12″ | 9.33″ |
| TBEH750X12 | .75″ | .98″ | 5.04″ | 3.33″ | 35.01″ | 23.01″ | 36.85″ | 24.85″ | 2.09″ | 1.00″ | 5.09″ | 12.59″ |
| TBEH750X18 | .75″ | .98″ | 5.07″ | 3.33″ | 47.01″ | 29.01″ | 48.85″ | 30.85″ | 2.09″ | 1.00″ | 5.12″ | 18.53″ |
| TBEH875X12 | .88″ | 1.13″ | 5.82″ | 3.78″ | 36.11″ | 24.11″ | 38.23″ | 26.23″ | 2.38″ | 1.25″ | 5.79″ | 12.16″ |
| TBEH100X12 | 1.00″ | 1.25″ | 6.56″ | 4.25″ | 37.65″ | 25.56″ | 40.06″ | 28.06″ | 3.00″ | 1.43″ | 6.50″ | 12.18″ |
| TBEH100X18 | 1.00″ | 1.25″ | 6.56″ | 4.25″ | 49.75″ | 31.65″ | 52.11″ | 34.11″ | 3.00″ | 1.43″ | 6.50″ | 18.28″ |
| EYE & EYE | EYE & HOOK | HOOK & HOOK | EYE & JAW | JAW & JAW | STUB END |
|---|---|---|---|---|---|
| TBEE (Size) | TBEH (Size) | TBHH (Size) | TBEJ (Size) | TBJJ (Size) | TBSS (Size) |
WARNING: Prop 65: Products supplied by CERTEX USA may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
Proof-Loaded to 2X the Working Load Limit Designed for Applications Where the Swivel Lifting Ring is Frequently Installed and Removed Installation Lugs Used to Easily Tighten or Loosen the Unit with a Striking Tool or Pipe Markings: X100 Brand, WLL, Conformity, Size...
