Applications:
Used as a repair link, connecting link or attaching device.
Packing:
3/16”, 1/4” and 5/16” sizes, packed 20 per carton, 3/8” and 1/2” sizes, packed 10 per carton.
| For Chain Size Inches | Carton | Display Pack | Clevis Opening Inches | Pin Diameter Inches | Reach Inches | Weight Per 100 Pieces Pounds | Working Load Limit* Pounds | ||
| CERTEX Cat. Ref. No. | Columbus McKinnon Code No. | UPC Code | |||||||
| 3/16 | CX06-0867 | D81001 | 39751 | 20 | 1 1/2 | 1/2 | 1/4 | 4 1/2 | 660 |
| 1/4 | CX06-0868 | D81101 | 39755 | 20 | 1 3/4 | 9/16 | 9/32 | 8 | 880 |
| 5/16 | CX06-0869 | D81201 | 39760 | 20 | 2 5/16 | 3/8 | 3/8 | 17 | 1,760 |
| 3/8 | CX06-0870 | D81301 | 39765 | 10 | 2 7/16 | 7/16 | 7/16 | 23 | 2,220 |
| 1/2 | CX06-0871 | D81501 | 39770 | 10 | 3 3/16 | 19/32 | 19/32 | 51 | 3,300 |
Zinc-plated NOT heat-treated. Use only with chain or equal or lower Working Load Limit
WARNING: Prop 65: Products supplied by CERTEX USA may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
