- Full rated capacity at any lifting angle
- 2.0t, 3.0t, 5.0t and 10.0t capacities available
- *NEW* 10t deep flange option (to 40mm)
- Quick and versatile rigging point for hoisting equipment
- Low headroom design
- Highly flexible – for lifting, pulling or as a semi-permanent anchor point
- Designed for both vertical and side loading applications – can be loaded at any angle
- Suitable for pulling and lifting at angles across the beam
- Designed to accommodate a wide range of beam widths
- Multidirectional adjusting screw spindle ensures a high clamping force to beam web
- Operating temperature -40°C to +80°C (temperature range of -60°C to +80°C available as an option)
- Factor of safety: 5:1 for straight pulling and lifting, 4:1 at all other angles
- Complies with ASME B30.20 and EN13155 :2003+A2 :2009
X100® PlateMate™ Swivel Lifting Rings
Proof-Loaded to 2X the Working Load Limit Designed for Applications Where the Swivel Lifting Ring is Frequently Installed and Removed Installation Lugs Used to Easily Tighten or Loosen the Unit with a Striking Tool or Pipe Markings: X100 Brand, WLL, Conformity, Size...
