• UNC Coarse Thread
| SIZE | STOCK NUMBER | WORKING LOAD LIMIT (LBS.) | WEIGHT/PIECE (LBS.) |
|---|---|---|---|
| 1/4″x1 1/2″ | SEB250X150W | 200 | 0.03 |
| 1/4″ x 2 1/4″ | SEB250X225W | 200 | 0.05 |
| 1/4″ x 3″ | SEB250X300W | 200 | 0.06 |
| 5/16″ x 2 1/4″ | SEB312X225W | 350 | 0.10 |
| 5/16″ x 3″ | SEB312X300W | 350 | 0.13 |
| 5/16″ x 4″ | SEB312X400W | 350 | 0.15 |
| 5/16″ x 4 1/2″ | SEB312X450W | 350 | 0.17 |
| 3/8″ x 1 1/4″ | SEB375X125W | 600 | 0.16 |
| 3/8″ x 3″ | SEB375X300W | 600 | 0.22 |
| 3/8″ x 4″ | EB375X400W | 600 | 0.25 |
| 3/8″ x 4 1/2″ | SEB375X450W | 600 | 0.28 |
| 1/2″ x 4″ | SEB500X400W | 1,000 | 0.40 |
| 1/2″ x 4 1/2″ | SEB500X450W | 1,000 | 0.45 |
| DIRECTION OF PULL (FROM IN-LINE) | ADJUSTED WORKING LOAD |
|---|---|
| 45 degrees | 30% of rated working load |
| 90 degrees | 25% of rated working load |
Warning: The full ratings of machinery eye bolts can only be achieved by pulling directly in line with the threads. For angled lifts, we recommend swivel hoist rings.
