APPLICATIONS
FEATURES
| ROPE SIZE DIAMETER | STOCK NUMBER | DESCRIPTION | REEL LENGTH | COLOR | WORKING LOAD LIMIT (lbs.) | MINIMUM BREAKING STRENGTH (lbs.) |
|---|---|---|---|---|---|---|
| 3/16” | POLY187X1200 | Polypropylene Twisted Rope | 1200′ | Yellow | 144 | 720 |
| 1/4” | POLY250X1200 | Polypropylene Twisted Rope | 1200′ | Yellow | 226 | 1,130 |
| 1/4” | POLY250X600 | Polypropylene Twisted Rope | 600′ | Yellow | 226 | 1,130 |
| 5/16” | POLY312X600 | Polypropylene Twisted Rope | 600′ | Yellow | 342 | 1,710 |
| 3/8” | POLY375X600 | Polypropylene Twisted Rope | 600′ | Yellow | 486 | 2,430 |
| 1/2” | POLY500X600 | Polypropylene Twisted Rope | 600′ | Yellow | 756 | 3,780 |
| 5/8” | POLY625X600 | Polypropylene Twisted Rope | 600′ | Yellow | 1,116 | 5,580 |
| 3/4” | POLY750X600 | Polypropylene Twisted Rope | 600′ | Yellow | 1,530 | 7,650 |
| 7/8” | POLY875X600 | Polypropylene Twisted Rope | 600′ | Yellow | 2,080 | 10,400 |
| 1” | POLY100X600 | Polypropylene Twisted Rope | 600′ | Yellow | 2,565 | 12,825 |
WARNING: Prop 65: Products supplied by CERTEX USA may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
Robust all-steel construction Super-quick adjustment to most I-, S-, and W-beams Durable baked enamel paint protection Stainless steel ID tag Individual serial number and test certificate
Fastest adjusting trolley requiring no tools to install Anti-drop plate ensures safe load handling Lightweight robust construction Durable baked enamel provides protection Fits to most I-, S-, and W-beams RoHS-compliant zinc-plated finish Glow-in-the-dark decals...
Robust all-steel fully-welded construction Super-quick adjustment to most I-beams ROHS-compliant zinc-plated finish Permanent engraved load rating Individual serial number and test certificate Made in USA
Lightweight and compact design for convenient mounting Automatic shut-off when rope reaches limit arm Dynamic and mechanical brake provides instant, safe braking Upper and lower limit switches for additional safety Sensor arm for motor shut-off to prevent reverse...
