Manila 3-Strand

Manila 3-Strand

APPLICATIONS

  • Industrial
  • Heavy marine
  • Construction & roofing
  • Lasso & lunging
  • Ornamental

FEATURES

  • Biodegradable rope
  • Firm grip when oily
  • Low stretch
  • Good abrasion resistance
  • Good chemical resistance
  • Will rot, store with care

Fiber Rope resistance icons


EMAIL PAGE

EMAIL PAGE


VIEW IN CATALOG

VIEW IN CATALOG


WARNINGS & CAUTIONS

WARNINGS & CAUTIONS

3 Strand, Twisted Manila Rope

ROPE SIZE DIAMETER STOCK NUMBER DESCRIPTION REEL LENGTH COLOR WORKING LOAD LIMIT (lbs.) MINIMUM BREAKING STRENGTH (lbs.)
1/4″ MAN250X1250 Manila Twisted Rope 1250′ Natural 108 540
1/4″ MAN250X600 Manila Twisted Rope 600′ Natural 108 540
5/16” MAN312X600 Manila Twisted Rope 600′ Natural 180 900
3/8” MAN375X600 Manila Twisted Rope 600′ Natural 243 1,215
1/2” MAN500X600 Manila Twisted Rope 600′ Natural 477 2,385
5/8” MAN625X600 Manila Twisted Rope 600′ Natural 792 3,960
3/4” MAN750X600 Manila Twisted Rope 600′ Natural 972 4,860
7/8” MAN875X600 Manila Twisted Rope 600′ Natural 1,386 6,930
1” MAN100X600 Manila Twisted Rope 600′ Natural 1,620 8,100

WARNING: Prop 65: Products supplied by CERTEX USA may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
