Folding Handle Enclosed Ratchet Binders

Folding Handle Enclosed Ratchet Binders

• Straight, heavy duty barrel
• Grab-Grab end fittings
• Fittings are yellow zinc plated
• Powder coated handle and barrel
• All load bearing fittings are forged
• Quenched and tempered
• Folding handle
• Enclosed gears


EMAIL PAGE

EMAIL PAGE


WARNINGS & CAUTIONS

WARNINGS & CAUTIONS

STOCK NUMBER TAKE-UP BARREL LENGTH HANDLE LENGTH SCREW DIAMETER END FITTINGS BEARING TO BEARING (CLOSED-OPEN) WORKING LOAD LIMIT (LBS.) PROOF LOAD LIMIT (LBS.) WEIGHT (LBS.)
GTEF375 8″ 10″ 15″ 1″ 3/8″ Grab x 2 25″ – 33″ 8,800 17,600 13
GTEF500 8″ 10″ 15″ 1″ 1/2″ Grab x 2 26″ – 34″ 12,000 24,000 17
GTEF625 8″ 10″ 15″ 1″ 5/8″ Grab x 2 26″ – 34″ 18,100 36,200 22




WARNING: Prop 65: Products supplied by CERTEX USA may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
