Crosby® Light Champion 404 Tail Board Snatch Block

Crosby® Light Champion  404 Tail Board Snatch Block

404 Tail Board

  • Forged alloy heat treated hooks.
  • Forged steel swivel tees, yokes and shackles
  • Hook and shackle assemblies on 4 1/2” through 14” sizes can be interchanged.
  • Can be furnished with bronze bushings or roller bearings.
  • Opening feature permits insertion of rope while block is suspended from gin-pole.
  • 3” thru 18” 418 and 419 blocks have exclusive bolt retaining spring to assure no lost bolts.
  • Can be furnished with SS-4055 hook latch.
  • Pressure lube fittings.
  • Fatigue rated.
  • 3” – 10” feature dual rated wireline sheaves.
Sheave Diameter (in.) Bearing Code 404 Tail Board Wire Rope Size (in.) †† Working Load Limit * (metric tons) Weight Each (lbs.) Replacement Sheave
CERTEX Cat. Ref. No. Crosby Stock No. 404 Tail Board CERTEX Cat. Ref. No. Crosby Stock No.
*3 BB 5/16-3/8 2 CX13-0062 46014
**3 BB CX13-0050 102016 5/16-3/8 2 2.7 CX13-0063 460147
**4 1/2 BB CX13-0051 102025 3/8-1/2 4 6.6 CX13-0064 2000232
6 BB
RB
CX13-0052
CX13-0053
102098 102114 5/8-3/4 8 15 CX13-0065 CX13-0066 460815
472688
8 BB
RB
CX13-0054
CX13-0055
102169 102187 5/8-3/4 8 21 CX13-0067
CX13-0068
461164
473277
10 BB
RB
CX13-0056 CX13-0057 102230 102258 5/8-3/4 8 29 CX13-0069
CX13-0070
461805
473776
12 BB
RB
CX13-0058 CX13-0059 178890 178934 5/8 8 36 CX13-0071
CX13-0072
462270
474141
12 BB
RB
CX13-0060 CX13-0061 102301 102329 3/4 8 36 CX13-0073 CX13-0074 462284
474150
14 BB
RB


5/8 8 CX13-0075 CX13-0076 463625
474150
14 BB
RB


3/4 8 CX13-0077 CX13-0078 463634
474775
16 BB
RB


3/4 15 CX13-0079 CX13-0080 4100056
4200028
16 BB
RB


7/8 15 CX13-0081 CX13-0082 4100065
4200037
18 BB
RB


7/8 15 CX13-0083 CX13-0084 464571
475792
18 BB
RB


1 15 CX13-0085 CX13-0086 4104640
6000000

* Ultimate Load is 4 times the Working Load Limit.
** Available in Bronze Bushed only. 3” and 4 1/2” have self lubricating Bronze Bushing.
† Fitted with 1 1/4” I D Swivel Eye.
†† May be furnished in other wire rope sizes.
NOTE: When ordering, please specify: size, block number, hook or shackle, bronze bushed or roller bearing, and wire rope size.
