Applications:
Used as a temporary or permanent link with proof coil or high test chain.
Packing:
Display pack.
| For Chain Size Inches |
Carton | Display Pack | Clevis Opening Inches | Pin Diameter Inches | Reach Inches | Weight Display Pack Pounds | Working Load Limit* Pounds |
||
| CERTEX Cat. Ref. No | Columbus McKinnon Code No. | UPC Code | |||||||
| 1/4 & 5/16 | CX06-0864 | M605 | 28926 | 30 | 7/16 | 3/8 | 1 3/16 | 10 | 3,900 |
| 3/8 | CX06-0865 | M606 | 28936 | 30 | 1/2 | 7/16 | 1 3/8 | 14 | 5,400 |
| 7/16 & 1/2 | CX06-0866 | M608 | 28941 | 10 | 5/8 | 9/16 | 1 3/4 | 11 | 9,200 |
Drop forged, heat-treated, carbon steel, zinc-plated.
