Note: Not limited to Single Chain Sling Applications
| Specifications | |||
| Size of Chain | Grade 80 Working Load Limits* Lbs. at 90° | Grade 100 Working Load Limits* Lbs. at 90° | |
| In. | mm | ||
| 9/32 | 7 | 3,500 | 4,300 |
| 3/8 | 10 | 7,100 | 8,800 |
| 1/2 | 13 | 12,000 | 15,000 |
| 5/8 | 16 | 18,100 | 22,600 |
| 3/4 | 20 | 28,300 | 35,300 |
| 7/8 | 22 | 34,200 | 42,700 |
| 1 | 26 | 47,700 | — |
| 1-1/4 | 32 | 72,300 | |
WARNING: Prop 65: Products supplied by CERTEX USA may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
Product Features: Large WLL range 0.3 t – 5 t Clear indication of the minimum WLL for all loading directions. Higher WLL by optimised attachment or application Rotatable 90° to the bolt-on direction under rated WLL Variable bolt lengths available for use in threaded...
