| SIZE | STOCK NUMBER | WEIGHT/1,000′ | BREAKING STRENGTH |
|---|---|---|---|
| 7/16″ | SSWRC437 | 356 lbs. | 16,300 lbs. |
| 1/2″ | SSWRC500 | 460 lbs. | 22,800 lbs. |
| 9/16″ | SSWRC562 | 590 lbs. | 28,500 lbs. |
| 5/8″ | SSWRC625 | 720 lbs. | 35,000 lbs. |
| 3/4″ | SSWRC750 | 1,040 lbs. | 49,600 lbs. |
| 7/8″ | SSWRC875 | 1,420 lbs. | 58,000 lbs. |
| 1″ | SSWRC100 | 1,850 lbs. | 75,200 lbs. |
NOT FOR AIRCRAFT USE. (“Aircraft Cable” has become an accepted industry term for small diameter 7×7 and 7×19 construction wire rope intended for industrial and marine application.) Read important warnings and information.
WARNING: Any warranties, expressed or implied, concerning the use of this product apply only to the nominal strength of new, unused wire rope. All equipment using this product must be properly used and maintained. Wire rope must be properly stored, handled, used and maintained. Most importantly, wire rope must be regularly inspected during use. Damage, abuse or improper maintenance can cause rope failure. Consult the AISI Wire Rope Users Manual, ASME or ANSI Standards, before usage. Wire rope removal criteria are based on the use of steel sheaves. If synthetic sheaves are used, consult the sheave equipment manufacturer. WARNING!
WARNING: Prop 65: Products supplied by CERTEX USA may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
