| Specifications | |||
| Size of Chain | Grade 80 Working Load Limits* Lbs. at 90° | Grade 100 Working Load Limits* Lbs. at 90° | |
| In. | mm | ||
| 9/32 | 7 | 3,500 | 4,300 |
| 3/8 | 10 | 7,100 | 8,800 |
| 1/2 | 13 | 12,000 | 15,000 |
| 5/8 | 16 | 18,100 | 22,600 |
| 3/4 | 20 | 28,300 | 35,300 |
| 7/8 | 22 | 34,200 | 42,700 |
| 1 | 26 | 47,700 | — |
| 1-1/4 | 32 | 72,300 | |
WARNING: Prop 65: Products supplied by CERTEX USA may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
Proof-Loaded to 2X the Working Load Limit Designed for Applications Where the Swivel Lifting Ring is Frequently Installed and Removed Installation Lugs Used to Easily Tighten or Loosen the Unit with a Striking Tool or Pipe Markings: X100 Brand, WLL, Conformity, Size...
The Dura-Mod® 2-Point/110-Metric Ton Spreader Beam can be configured in spreads of 6' to 59'. Order Spreader Sections, End Fittings, Drop Links, and Bolts separately to build the beam you want. Lightweight in comparison to fixed/multiple point beams Easy to transport...
The Dura-Mod® 2-Point/70-Metric Ton Spreader Beam can be configured in spreads of 3' to 45'. Order Spreader Sections, End Fittings, Drop Links, and Bolts separately to build the beam you want. Lightweight in comparison to fixed/multiple point beams Easy to transport...
The Dura-Mod® 2-Point/50 Metric Ton Spreader Beam can be configured in spreads of 3 to 41 feet. Lightweight in comparison to fixed/multiple point beams Easy to transport and store; single longest component is only 12'L Components can be reconfigured, added to or...
