| SIZE | STOCK NUMBER | WEIGHT/1,000′ | BREAKING STRENGTH |
|---|---|---|---|
| 3/8″ | GFC3756X19 | 230 lbs. | 10,980 lbs. |
| 7/16″ | GFC4376X19 | 320 lbs. | 14,880 lbs. |
| 1/2″ | GFC5006X19 | 420 lbs. | 19,260 lbs. |
| 9/16″ | GFC5626X19 | 530 lbs. | 24,200 lbs. |
| 5/8″ | GFC6256X19 | 660 lbs. | 30,000 lbs. |
| 3/4″ | GFC7506X19 | 950 lbs. | 42,800 lbs. |
Note: According to Federal Specifications RR-W-410D, preformed right regular lay.
| SIZE | STOCK NUMBER | WEIGHT/1,000′ | BREAKING STRENGTH |
|---|---|---|---|
| 3/8″ | GIWRC3756X19 | 260 lbs. | 13,600 lbs. |
| 7/16″ | GIWRC4376X19 | 350 lbs. | 18,360 lbs. |
| 1/2″ | GIWRC5006X19 | 460 lbs. | 24,000 lbs. |
| 9/16″ | GIWRC5626X19 | 590 lbs. | 30,200 lbs. |
| 5/8″ | GIWRC6256X19 | 720 lbs. | 37,000 lbs. |
| 3/4″ | GIWRC7506X19 | 1,040 lbs. | 53,000 lbs. |
Note: According to Federal Specifications RR-W-410D, preformed right regular lay.
NOT FOR AIRCRAFT USE. (“Aircraft Cable” has become an accepted industry term for small diameter 7×7 and 7×19 construction wire rope intended for industrial and marine application.) Read important warnings and information.
WARNING: Any warranties, expressed or implied, concerning the use of this product apply only to the nominal strength of new, unused wire rope. All equipment using this product must be properly used and maintained. Wire rope must be properly stored, handled, used and maintained. Most importantly, wire rope must be regularly inspected during use. Damage, abuse or improper maintenance can cause rope failure. Consult the AISI Wire Rope Users Manual, ASME or ANSI Standards, before usage. Wire rope removal criteria are based on the use of steel sheaves. If synthetic sheaves are used, consult the sheave equipment manufacturer. WARNING!
WARNING: Prop 65: Products supplied by CERTEX USA may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
The Modulift Spreader is modular in length, and every spreader consists of 1 pair of End Units and Drop Links, with intermediate struts that can be bolted into the assembly to achieve different spans. MOD 400/600 has an assembled span ranging from 6ft to 78ft in 1ft...
The Modulift Spreader is modular in length, and every spreader consists of 1 pair of End Units and Drop Links, with intermediate struts that can be bolted into the assembly to achieve di erent spans. MOD 400/500 has an assembled span ranging from 6ft to 78ft in 1ft...
The Modulift Spreader is modular in length, and every spreader consists of 1 pair of End Units and Drop Links, with intermediate struts that can be bolted into the assembly to achieve di erent spans. MOD 400/400 has an assembled span ranging from 6ft to 78ft in 1ft...
The Modulift Spreader is modular in length, and every spreader consists of 1 pair of End Units and Drop Links, with intermediate struts that can be bolted into the assembly to achieve di erent spans. MOD 250/400 has an assembled span ranging from 6ft to 68ft in 1ft...
